FCU Selection Software
Overview
Fully configurable fan coil unit software
Features
- Fully configurable fan coil unit selection software
- Flexible database allows for easy configuration of:
- 6 unit ranges
- 10 models per range
- 5 speeds per model
- 9 external resistances per model
- 10 main costs and 10 labour costs per model
- 10 unit option costs and labour costs per model
- 5 control manufacturers
- 10 option costs and labour costs per manufacturer, common for all ranges
- 5 control option costs and labour costs, common for all ranges
- The database can be extended upon request
- Dedicated configurable coil selection dll for accurate coil calculations. Water coils are standard, DX or electric coils upon request.
- Option for imperial or metric units
- Automatic price list generator to create a unique pricelist based upon the options and range you require
- Maximum performance calculation generator for a range based upon your entering air conditions, external resistance and maximum noise level. An invaluable pre selection tool for designers
- Unit quick selection module. Enter 6 items of data in a spreadsheet for each unit. Selects a unit per second based upon your client's parameters. Change water, air, control and unit parameters at will and reselect based upon the same spreadsheet
- Unit standard selection module to add units to a quick selection or for a small quantity of units
- Fully configurable project summary screen to change unit handings, references, quantities etc. at will
- Internal costing sheet giving detailed cost breakdowns for each unit selected
- Full quotation printout with summary prices, unit and control valve schedules
- Configurable for your specifications
